- Compact and low-profile for minimal obstruction of audience sightlines
- 50° x 90° nominal coverage
- Bi-amplified or full-range passive operation
- Differential Drive® woofer with neodymium magnet for high power capacity and very light weight
- 4" (voice coil) diameter compression driver with neodymium magnet
Specifications
Power Rating 800 W / 1600 W / 3200W Frequency Range (-10dB) 60 Hz - 20 kHz Dimensions (H x W x D) 629 mm x 432 mm x 324 mm (375 mm stage height) 24.75 in x 17 in x 12.75 in (14.75" stage height) Coverage Pattern (-6 dB) 50° x 90° nominal Crossover Modes Passive / Bi-amp Crossover Frequency 1.1 kHz Maximum SPL (1m) 127 dB SPL continuous (133 dB SPL peak) Sensitivity 98 dB SPL LF Driver 1 x JBL 2265H 380 mm (15 in) Differential Drive® woofer 8 Ohms HF Driver 1 x JBL 2453H-SL, 38 mm (1.5 in) exit compression driver, 100 mm (4 in) voice coil and neodymium magnet Nominal Impedance 8 ohms Active Tunings Tunings available at www.jblpro.com Enclosure Symmetrical stage monitor, 15/18 mm, plywood Finish Black DuraFlex™ finish Grille Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing Inputs Neutrik® Speakon® NL-4 (x2), one on each end Net Weight (each) 21 kg (46.0 lb) Outputs 1 x XLR
