Features
- Best in class audio performance
- 2000 Watt Class-D amplifier module
- Intrinsic Correction™ tuning and loudspeaker management
- DMT™ (Directivity Matched Transition) design provides excellent power response and consistent performance across the listening are
- Refined, professional appearance looks great in any application
- Rugged ABS enclosure for long life and lasting durability
- Deployment in either main PA or floor monitor position
- Factory Presets and savable/recallable Scenes for commonly-used application
- Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contour
- Dual pole cup mounts (standard and 7.5 degree down-tilt)
- M10 fittings for flown applications
- Optional security panel prevents unauthorized tampering of controls
- Complete EASE and CAD information available online
- 6-Year Warranty (with product registration)
Configuration | Multi-purpose, 2-way powered loudspeaker |
LF Transducer | 10" (254 mm), cone |
HF Transducer | 1.4" (35.6 mm) titanium diaphragm compression driver |
Frequency Response (-6 dB) | 56 Hz - 20 kHz |
Frequency Range (-10 dB) | 50 Hz - 20 kHz |
Nominal Coverage Angle | 90° Axisymetric |
Maximum Rated SPL1 | 130 dB @1 M, peak 124 dB @ 1 M, continuous |
Controls | Power |
Indicators | Monochrome LCD Display 1.75" x 1" (45 mm x 25.4 mm) |
Connectors | 2 x locking XLR/F ¼" combo (Mic/Line Input and Hi-Z/Line Input |
AC Power Input | Universal power supply 100 – 240 VAC, 50 – 60 Hz |
AC Power Consumption 1/8th Power2 | 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A |
AC Power Consumption - Standby | .2A at any voltage |
Enclosure Details |
|
Enclosure Enclosure | Impact Resistant ABS |
Attachment Points | 2 x M10 threaded inserts plus Pull-Back |
Color | Black (RAL 9011) |
Grille | 18 Gauge powered coated steel, internal cloth lining |
Dimensions (HxWxD) | 20.4 x 12.6 x 11.8 in |
Net Weight | 14.5 kg (32 lbs) |
Shipping Weight | 17.6 kg (38.8 lbs) |
Regulatory | CE, WEEE, UL, China RoHS, RoHS II, FCC Class B |
Optional Accessories | K10 Tote, K10 Outdoor Cover |
