Features
High Output in an ultra-compact form factor
2000 Watt Class D amplifier module
12-inch, long-excursion driver; 6th order bandpass design
Intrinsic Correction™ tuning and loudspeaker management
Refined, professional appearance looks great in any application
Rugged painted wood enclosure for long life and lasting durability
Deployment in either vertical or horizontal positions with dual M20 speaker pole fittings
Optional KS-LOC security cover prevents unauthorized tampering of controls
Complete EASE & CAD information available online
| SPECIFICATIONS | KS112 |
| Configuration | 6th-Order Bandpass Subwoofer |
| LF Transducer | 12-inch (305 mm), Cone |
| Frequency Response (-6 dB) | 41 Hz - 108 Hz |
| Frequency Range (-10 dB) | 38 Hz - 121 Hz |
| Maximum Rated SPL1 | 128 dB @ 1 m (peak) |
| Amplifier | Class D 2000W (peak) |
| Cooling | Low-noise, variable speed fan |
| Controls | Power On/Off Gain Control Rotary encoder 2 x selection buttons |
| Indicators | 2 x Power LED (front and rear) Input Signal LED Limiter Active LED |
| Connectors | 2 x locking XLR/F 1/4-inch combo 2 x XLR/M (Loop-thru Output) 1 x locking IEC power connector |
| AC Power Input | Universal power supply 100 - 240 VAC, 50 - 60 Hz |
| AC Power Consumption | 100 VAC, 2.4 A / 120 VAC, 2.0 A / 240 VAC, 1.3 A |
| Enclosure Details | |
| Enclosure | 15 mm Birch Plywood |
| Color | Black (RAL 9011) |
| Grille | Internal woofer cover |
| Dimensions (HWD) inches | 24.5 x 15.5 x 24.25 |
| Dimensions (HWD) mm | 622 x 394 x 616 |
| Net Weight | 28.4 kg (62.6 lbs) |
| Shipping Weight | 34.5 kg (76 lbs) |
| Regulatory | CE, WEEE, UL, China RoHS, RoHS II, FCC Class B |
| Included Accessories | 4 x Low-Noise, Heavy Duty Casters |
| Optional Accessories | KS112 CVR Transport Cover, KS-LOC Lock-Out Cover SP-16X Extension Pole, SP-36 Extension Pole |
