FEATURES

• SSA-160DP is a PA mixer amplifier of rated output 160 Watts. It has an built-in MP3 Digital Player, making it a versatile multi-application music centre. The Digital Player accepts USB drives & SD/MMC cards, reproducing clear, high quality music. A remote control is provided for controlling the functions of the Digital Player from a distance.

• This, combined with 5 Microphones inputs, 2 Aux inputs, and provision for multiple speaker connections makes this

  product ideally suited for a variety of music programmes and public address applications.

• 5 Mic & 2 Aux Inputs.

• Built-in MP3 player with remote control for USB, SD/MMC card reader.

• Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.

• Line Input for connecting the output from any external mixer or permitting SSA-160DP to be used as a Booster Power

  Amplifier.

• Resettable circuit breaker for protection against overload and short circuit.

• Provision for instant transfer to DC power (Car Battery) if AC power fails.

• Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.

• 5 LED array for output level monitoring.

SPECIFICATIONS

Power Output	220W Max., 160W RMS at 10% THD
	140W RMS at 5% THD, 120W RMS at 2% THD
Output Regulation	2 dB, no load to full load at 1kHz
Input Channels	5 × Mic 0.65mV/4.7k, 2 × Aux 100mV/470k 1 × Line 1V/20k
Frequency Response	50-15,000Hz ±3dB
Signal to Noise Ratio	60dB
Tone Controls	Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz
Outputs	Preamp 200mV/600, Line 1V/1k
Speaker Outputs	4, 8, 70V & 100V
Digital Player	MP3 Player with USB, SD and MMC Card Reader
Power Supply	AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery)
Power Consumption	AC: 320VA DC: 4A
Dimensions	W420 × H155 × D320 mm
Weight	13.8kg
