OctaLine 12 LA
12" Self-Powered, Constant Curvate Array
TECHNICAL SPECIFICATIONS
ACOUSTICAL
SPECIFICATIONS
• Freq. Response (-3 dB) : 70 Hz - 20 kHz
• Freq. Range (-10 dB) : 55 Hz - 20 kHz
• H Dispersion : 100° (- 6 dB)
• V Dispersion : 20”, array dependent
• Crossover : 1.4 kHz Active
• Max Output : 130 dB, 136 dB Peak
SYSTEM SPECIFICATIONS
• Recommended Subwoofers : See Systems
Chart for compatible subwoofers
• Recommended System Control : Delta 98
FIR, Delta 48, PW 6 or built-in control for
smaller set-ups
LF TRANSDUCER
• 12CT75 - 12" Low frequency driver
• 750W AES, 3000W Peak
• 3" Voice Coil - Ferrite Magnet
• Compliant & Controlled spectre-spider
• Enhanced ventilation due to optimized heat
paths
HF TRANSDUCER
• A14CT75 - 1.4” Exit HF Compression Driver
• 50W AES, 200W Peak
• 3” Voice Coil - Ferrite Magnet
• Precise waveguide maintaining horizontal
dispersion upto 18 kHz
AMPLIFIER & DSP
SPECIFICATIONS
• 3000W - Two Channel Class-H Amplifier
• M1 Power Factor Crossover Module
• Enhanced Amplifier efficiency
• 3-Stage System protection process
• 24-Bit Built-In DSP for Superior voicing
• On-Board 2 Channel mixer Bluetooth
• 2 x TRS Jack mic input, 1 x XLR line input,
1 x XLR line output & 1 x Bluetooth input
• 2 x 16A PowerCon Connectors, Input & Thru
HOUSING
• Marine Birchply Enclosure
• Granular Scratch Free Polyurea Paint
• Perforated Black, Pressed Steel Grills
• Integrated Handles on Either Side
• 2-Point Steady Rig System
• Constant Curvature
• Tethered Quick-lock Pins
• Can be flown or stacked over the OctaLine
84FS without the need of an array frame
• Max. of 6 units in one hang with the
Acc 82 AF
OPERATING PARAMETERS
• Operating positions: Flown or
Ground stacked with the correct Array
Frame or Accessory
• Maximum permitted ambient temperature
(Ta max) 40° C (104° F)
• Minimum permitted ambient temperature
(Ta min): 4° C (39.2° F)
IP SPECIFICATIONS
• IP 43 - Standard protection against dust & splashes
AESTHETIC
SPECIFICATIONS
• British Acoustics Signature Umber Brown
Tone
• Non Reflective, Matte Black Grills
• Available in a RAL code of your choice (24
nos, minimum)
OPTIONAL ACCESSORIES
• See system chart for the System Accessories
SIZE
• Product : 431x 749 x 450 mm (H x W x D)
• Product : 17 x 29.5 x 17.75 inch (H x W x D)
• Packed individually
WEIGHT
• Net : 42.6 Kgs
• Net : 93.91 Lbs
SHIPPING INFORMATION
• Carton Size
489 x 621 x 633 mm (H x W x D)
19.25 x 24.4 x 25 inch (H x W x D)
• Gross Weight - 30.45 Kgs / 67.17 Lbs
• Packed : Individually
